TIGER COMBINED CHAIN BLOCK & GEARED TRAVEL TROLLEY MODEL CCBTGS, 1.0t CAPACITY 80-128mm

  • 1.0t SWL Capacity, to suit a beam width range of 80-128mm with a plain powder coated finish
  • The CCBTGS geared trolley range is from 0.5t to 30.0t safe working load
  • Twin bar or single bar trolley options possible
  • The unit can be chained to any height of lift to meet your exact requirements
  • Ideal for locations where headroom is limited
  • Extended beam width available
  • Tiger trolley wheels are specially designed with a convex profile eliminating potential point loading
  • The wheels run on sealed bearings for smoother rolling with less effort and maintenance
  • The anti-drop plates design ensures extra safety, and also prevents damage to the wheels when contacting end rail stoppers
  • Chain carrier available
  • Geared and plain trolley versions available
  • The 5:1 factor of safety allows for use with manual or powered hoists
  • Operating temperature of -30°C to +50°C (temperature range of -50°C to +50°C available as an option)
  • Corrosion or Spark Resistant versions also available

Certification

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC.

Due to our policy of continual product development, dimensions, weights and specifications may change without prior notice. Please check with the sales team when ordering.

. Product Code Capacity (tonne) D – Track width Dimensions (mm) Min. curve radius (m) Net Weight (kg) @ std HOL
Range 1 (mm) Range 2 (mm) Range 3 (mm) Minimum Range 1 & Range 2 with optional locking device (mm) A B C H F G L
Single Bar Trolleys CCBTGS-0050 0.5 80-128 80-203 158-310 90 195 180 106 310 20 64 79 0.8 20
CCBTGS-0100 1 80-128 80-203 160-310 90 213 180 113 340 20 71 82 1 23.5
CCBTGS-0200 2 112-154 112-230 218-310 125 236 195 136 420 25 80 94 1.3 37.5
CCBTGS-0300 3 111-153 111-230 217-310 111 275 198 146 504 25 97 126 1.5 53.5
Twin Bar Trolleys CCBTGT-030T 3 105-153 105-230 207-310 320 194 142 460 30 110 132 1.5 58.5
CCBTGT-0500 5 126-194 126-305 352 218 166 545 28 131 143 1.5 74.5
CCBTGT-0600 6 126-194 352 218 166 587 28 131 143 2 93
CCBTGT-1000 10 125-320 230 394 282 243 660 40 117 119 1.5 144
CCBTGT-1500 15 150-320 150 509 342 276 827 42 182 174 2.7 290
CCBTGT-2000 20 125-320 190 754 284 243 950 40 117 119 6 321
CCBTGT-3000 30 150-320 155 1009 339 270 1145 42 182 174 6 621
CCBTGT-3500 35 150-320 165 1009 335 274 1145 32 182 174 6 651
